Refrigeration Capacity:

60.0 kW/51.600 kcal/h or 1.238.000 kcal per 24 hours*.

Variable production range:

Output can be varied from 1.380 L/h with 40% ice concentration to 4.740 L/h with 10% ice concentration**.

Filtration:

A 5-micron filter fitted to water intake to prevent ingestion of foreign objects.

Minimum salt concentration:

System requires 3% NaCl concentration for OptimICE® production.

Power Consumption:

33.0 kW

Dimensions in cm (LxWxH):

226x136x173

Weight:

1.280 kg

Refrigerant:

R-404A /R-449A

PreCooler:

Optional PreCooler ensures uniform production of OptimICE® over a large inlet water temperatures range.

Condenser:

Cooling water requirements:

5°C = 3.600 L/h

10°C = 4.400 L/h

15°C = 6.000 L/h

20°C = 11.700 L/h

* Appr. 1 kcal is required to achieve a one-degree temperature reduction in one kilogram of fish. ** Based on seawater inlet temperature of 0°C.

A guarantee is given for 12 months after test-run, or max 18 months from delivery of equipment from KAPP factory.

-

The guarantee covers only duplicate parts delivered EXW KAPP factory if failure is caused by original fault of material and/or workmanship.

-

The guarantee does not cover any leakage of refrigerant.

-

This guarantee is contingent upon the installation being approved and/or started by our supervisor at conditions agreed upon by the parties.
